MLE Electric Bike
Size & Fit
| ★ | Recommended Height | 5'1"~6'4" |
| A | Top Tube Horizontal | 55 cm / 21.6 in |
| B | Wheelbase | 112 cm / 44.1 in |
| C | Stand Over Height | 47 cm / 18.5 in |
| D | Handle Bar Length | 65 cm / 25.6 in |
| E | Total Length | 172 cm / 67.7 in |
| F | Seat Height Min / Max | 85~100 cm / 33.4~39.4in |
| G | Handle Bar Height Min / Max | 100~104 cm / 39.4~40.9in |
| H | Front Basket |
31.5 x 30.5 x 12 cm 12.4 x 12 x 4.7 in |
| I | Rear Rack |
43 x 14 cm 16.9 x 5.5 in |
| J | Wheel Size | 36'' x 1.95 |
| K | Seat Size |
25 x 21 cm 9.8 x 8.3 in |
Components
| Weight |
G.W. 68.3 lbs, N.W. 61.7 lbs |
| Frame | 6061 Aluminum |
| Fork | Hi-Ten Steel, Rigid Fork, Shock Absorber Front Fork |
| Handle Bar | 22.2 x 640 x 1.4T x 25.4 |
| Stem | 25 x 4 x 25.4 x 180 x 25.4, EX:30 |
| Grip | Soft PVC Rubber |
| Saddle | Comfortable Big Vacuum-Foamed Seat |
| Seat Post | 27.2 x 300 x 1.4T |
| Seat Post Clamp | 31.8mm, Quick Release |
| Shifter | Shimano Tourney TX30-7, 7-Speed |
| Derailleur | Shimano Altus TZ500 |
| Chainwheel | 152mm Alloy Crank, 38T Steel Chainring |
| Chain | P50, 1/2 x 3/32 x 118L |
| Freewheel | 7-Speed, 14-28T |
| Pedal | Black Plastic, 9/16-inch |
|
Display
|
Intelligent Digital LCD Display Appears More Clearly in Sunlight, Multicolor
|
| Brake | StarUnion Mechanical Brake, Alloy, 160mm Rotor |
| Brake Level | Alloy 3-Finger Mechanical Brake with Electrical Cut-Off Function |
| Rim | Alloy 26-inch x 1.75-inch x 13G x 36H |
| Tire | 36 x 1.95 |
| Spokes | Stainless, 13G |
| Fenders | With |
| Rear Rack | With |
| Front Basket | Front Iron Frame, Frosted Black |
| Assembly | 85% |
| Colors | 6 Colors |
| Carton Size | 144 x 22 x 70 cm /
56.7 x 8.7 x 27.6 inches |
| Load Capacity |
350LBS
|
| Recommended Height | 5'1"~6'4" |
Specification
| Motor | 36V*350W |
| Battery | 36V*10.4Ah |
| Range | 25~30 Miles |
| Charger | 110-240V 42V 2A |
| Charging Time | 5 Hours |
| Max Safe Speed | 20 Mph |
| Controller | Sine Wave FOC 36V 16amp Peak |
| Sensor | 24 Signals Node Sensor |
| Throttle | Thumb Throttle |
| Wire Harness | All Water-Resistant |
| Front Light | 36V, 25LUX, Reflector |
| Rear Light | LED Brake Highlight Function |
- Phone Holder x 1
- Water Bottle x 1
- Handlebar Bag x 1
- Mirrors (Pair) x 1
Protect your trike and bike and prevent theft.
- Large Size: 75"×30"×44"(L×W×H), fits most adult trikes.
- Various Colors: Choose from three different colors according to your preferences.
- Easy to Storage: Easy to take with you anywhere with a matching carrying bag.
- Lock-Hole Design: Lock hole design at the front wheels area allows using a bike lock with the cover on.
- Waterproof Material: Made of waterproof polyester with PU and UV coating protects bicycles from weather, dust, dirt, and sun damage.
- Black Silver
- Black Orange
- Full Black
- Size: 16.14" x 8.27" x 3.15"
- Weight: G.W. 39.48 lbs, N.W. 36.38 lbs
- Cool Black
- Ivory White
Providing you with professional and excellent protection,
whether on or off the road.
- Cool Gray
- White
- M
- L
Automatically adjust the color based on the light conditions, providing clear and comfortable vision while cycling.
- Black
- White
Bike mirrors can greatly enhance safety while riding on busy roads, providing an additional line of sight, effectively monitoring approaching vehicles, pedestrians, or other cyclists from behind, helping us make informed decisions on when to change lanes, make turns, or take any necessary defensive actions.
A bike handlebar bag is a convenient and versatile accessory designed to securely hold your essentials while riding. With a handlebar bag, you can keep your belongings within reach and organized, making it easy to access them whenever needed.
A bike phone holder can grip each corner of your phone tightly, ensuring its safety even on bumpy roads, which allows you to access navigation apps, track your ride, or stay connected while riding.
Safety
Our approach to accessibility goes beyond physical design
Comfort
And inclusivity, making sure every rider feels confident and empowered
Accessibility
It encompasses affordability, ensuring our E-Bikes are within reach
Powerful Motor
Equipped with a 350W rear-drive motor, this ebike offers consistent and smooth performance, ideal for everyday use.
Battery Power
Equipped with a removable 36V*10.4Ah lithium battery, this ebike provides a range of 25 to 30 miles on a single charge, ensuring ample power for daily commutes or casual rides.
Shimano 7 Speed
Equipped with the Shimano 7-speed gear system, this eBike ensures smooth and effortless speed transitions, providing superior comfort and control on every ride.
Adjustable Seat
The wide, soft cushion offers exceptional comfort for long rides, while the adjustable design ensures it fits riders of different heights and postures with ease.
